DRD Can, Drawn Can
2-piece cans made from pre-coated and pre-printed metal sheet which is drawn into the cup shape, usually matched with easy-open aluminum ends.
Features of DRD and drawn cans
-
POINT1Light weight and resource saving
As they are 2-piece cans, they weigh less and require less resources than 3-piece welded cans.
-
POINT2High display effect
By printing metal sheet before forming into can shape, graphics design can be displayed not only on the can sidewall but also on the can bottom.
Since the graphics printed on the sidewall are distorted after can forming, there is a need to compensate for this distortion by reverse-distorting the graphics (distortion printing), thus restoring the original graphics after can forming. -
POINT3A wide range of product lineup
In addition to round shaped cans, we offer rectangular, oval and cone-shaped (PC) cans.
We also have DR cans with PET film laminated on the can internal surface to improve their compatibility with the contents and reduce environmental impact.
Main applications
Food: Seafood (tuna, mackerel, saury, etc.), meat, boiled beans, red bean jelly, pudding, jelly, etc.
Others: Pet food
Product lineup
| Can type | Code name | Diameter x Can height after seaming | Fill volume |
|---|---|---|---|
| DR Can (inside laminated) | T3RF1 (Tuna No. 3 DR Can) | 211×37.8 mm | 107 ml |
| DR Can (inside laminated) | 90RF31C (Pocket No. 4 DR Can) | 301×28.8 mm | 91 ml |
| DR Can (inside laminated) | F3RF31C （Flat No. 3 DR Can） | 301×33.0 mm | 109 ml |
| DR Can (inside laminated) | 220RF31B（No. 6 DR Can） | 301×57.2 mm | 220 ml |
| DR Can (inside laminated) | 180RF31B (Portable DR Can） | 301×46.8 mm | 175 ml |
| DR Can (inside laminated) | 200RF7 (Tuna No. 2 DR Can） | 307×44.4 mm | 194 ml |
| DR Can (aluminum) | 100RLS | 301×32.4 mm | 100 ml |
| DR Can (aluminum) | 130RLS | 301×38.9 mm | 130 ml |
| Drawn Can (tinplate) | O1 (Oval No. 1 Can) | Oval (158.9 mm×106.7 mm)×38.5 mm | 448 ml |
| Drawn Can (tinplate) | O3 (Oval No. 3 Can) | Oval (125.7 mm×83.0 mm)×31.5 mm | 222 ml |
| Drawn Can (aluminum) | O120L | Oval (105.0 mm×65.0 mm)×29.2 mm | 117 ml |
| Drawn Can (tinplate) | D3B (Rectangular No. 3 Can B) | Rectangular (106.2 mm×74.6 mm)×22.0 mm | 121 ml |
| PC Can (Cone-shaped Can) | PCS24 | (211 dia. top, bottom 52.0 mm)×32.4 mm | 62 ml |
| PC Can (Cone-shaped Can) | PCS22 | (211 dia. top, bottom 52.0 mm)×34.4 mm | 74 ml |
| PC Can (Cone-shaped Can) | PCS17 | (301 dia. top, bottom 64.0 mm)×27.5 mm | 72 ml |
